HARDYPHONE®

Atex telephones HARDYPHONE

ATEX Zones 1-21 and 2-22 -40°C + 60°C.

All telephones in the HARDYPHONE-Ex® range are equipped with SMART functionalities that include the self-test (AFD) and remote interrogation function, using the TelDia® interrogation and analysis software. The HARDYPHONE-Ex® range is designed to operate at temperatures between -40°C and +60°C.
A very important feature is the ATEX approval for analog telephone lines powered up to 160Veff (100Vac + 60Vdc), without limitations on all commercial PBXs.

TEL569T
Zones 1-21, 2-22 II2GD

PDF icon TEL569T
PDF icon Cert_ATEX
PDF icon Cert_IECEx

TEL569T is an ATEX analog telephone equipped with a telephone keypad with 15 dual function buttons, with 8 memories for short numbers that can be recalled with the Fn key. This is an analog telephone suitable for telephone lines with voltage up to 60Vdc + 100Vac (160Vrms), which can, therefore, be connected to any PABX on the market.

  • Body Aluminium
  • Handset Aluminium
  • Protection IP66 – IK10
  • Temperature -40°C +70°C
  • Humidity up to 98%
  • MTBF >180.000 h
  • MTTR 3 min
  • Metal buttons 15 buttons Ø 16mm
  • Ringtone 85dB at 1 meter
  • Handset cord INOX 200kg
  • LED «on line» Red
Protection Grade
  • Ex eb ib mb IIC T5/6 (II2GD)
Smart Options
  • AFD Automatic Fault Detection
  • Blue «status» LED
  • TelDia compatibility
Order Codes
  • TEL569T analog
  • TEL569TSm analog Smart

TEL569M0
Zones 1-21, 2-22 II2GD

PDF icon TEL569M0
PDF icon Cert_ATEX
PDF icon Cert_IECEx

TEL569M0 is an analog ATEX telephone without keypad for emergency function and Hot-Line. This is an analog telephone suitable for telephone lines with voltage up to 60Vdc + 100Vac (160Vrms), which can therefore be connected to any PABX on the market.

  • Body Aluminium
  • Handset Aluminium
  • Protection IP66 – IK10
  • Temperature -40°C +70°C
  • Humidity up to 98%
  • MTBF >180.000 h
  • MTTR 3 min
  • Ringtone 85dB at 1 meter
  • Handset cord INOX 200kg
  • LED «on line» Red
Protection Grade
  • Ex eb ib mb IIC T5/6 (II2GD)
Smart options
  • AFD Automatic Fault Detection
  • Blue «status» LED
  • TelDia compatibility
Order Codes
  • TEL569M0 analgico
  • TEL569M0Sm analogico Smart

TEL569M1..4
1 to 4 buttons

PDF icon Cert_ATEX
PDF icon Cert_IECEx
PDF icon TEL569M4

TEL569M0..M4 is an analog ATEX telephone equipped with 1 to 4 autodialing buttons, suitable to dial pre-stored numbers. This is an analog telephone suitable for telephone lines with voltage up to 60Vdc + 100Vac (160Vrms), which can therefore be connected to any PABX on the market.

  • Body Aluminium
  • Handset Aluminium
  • 1 to 4 aluminum buttons
  • Protection IP66 – IK10
  • Temperature -40°C +70°C
  • Humidity up to 98%
  • MTBF >180.000 h
  • MTTR 3 min
  • Ringtone 85dB at 1 meter
  • Handset cord INOX 200kg
  • LED «on line» Red
Protection Grade
  • Ex eb ib mb IIC T5/6 (II2GD)
Smart Options
  • Rilevazione automatico del guasto AFD
  • LED Blu di buon funzionamento
  • Compatibilità TelDia
Order codes
  • TEL569M1 analogico - 1 pulsante
  • TEL569M4 analogico - 4 pulsanti

TEL569T INMETRO

PDF icon CPEx 22.0697 X.pdf

TEL569T is an ATEX analog telephone equipped with a telephone keypad with 15 dual function buttons, with 8 memories for short numbers that can be recalled with the Fn key. This is an analog telephone suitable for telephone lines with voltage up to 60Vdc + 100Vac (160Vrms), which can, therefore, be connected to any PABX on the market.

  • Body Aluminium
  • Handset Aluminium
  • Protection IP66 – IK10
  • Temperature -40°C +70°C
  • Humidity up to 98%
  • MTBF >180.000 h
  • MTTR 3 min
  • Metal buttons 15 buttons Ø 16mm
  • Ringtone 85dB at 1 meter
  • Handset cord INOX 200kg
  • LED «on line» Red
Protection Grade
  • Ex eb ib mb IIC T5/6 (II2GD)
Smart Options
  • AFD Automatic Fault Detection
  • Blue «status» LED
  • TelDia compatibility
Order Codes
  • TEL569T-INMETRO analog
  • TEL569TSm-INMETRO analog Smart
