ERCOTEL-Plus®

Details, that make the difference

The ERCOTEL® range also includes some versions, known as Blue Light Telephones, used as emergency telephones in areas open to the public. The Blue light placed on the top of the phone is kept permanently lit, for the purpose of make the telephone point visible in a clear and unambiguous way, even at night. Almost all models of the ERCOTEL® series are also available in a GSM version, as well as a bi-standard version (see below).

BLT700T blue light

BLT700T is equipped with a telephone keypad with 14 dual function buttons, with 8 memories for memorized numbers activated by Fn key. The BLT700M0 version, on the other hand, has no keyboard and is equipped with the Hot-Line and autodialing function. A Blue optical indicator (LED or Xeno) placed on the top carries out the double function of indication of presence and alarm. Smart features are available by default.

  • Protection: IP66 – IK10
  • Temperature: -40°C +70°C
  • Humidity: up to 98%
  • MTBF: >180.000 h
  • MTTR: 3 min
  • Keypad aluminium Ø16mm
  • Bell 95dB at 1 meter
  • Handset cord INOX 200kg
  • LED «on line» Red
Smart Options
  • AFD Automatic Fault Detection
  • TelDia compatibility
  • LED «status» Blu
Accessories
  • Bell 110dB (230Vac)
Order codes
  • BLT700TSm analog keypad
  • BLT700M0Sm analog w/keypad
  • BLT700TSm-ip VoIP keypad
  • BLT700M0Sm-ip analog w/keypad
  • BLT700TSm-GSM GSM keypad
  • BLT700M0Sm-GSM GSM w/keypad

GSM700T
GSM700M0

GSM700T is equipped with a telephone keypad with 14 dual function buttons, with 8 for memorized numbers activated by Fn key. The GSM700M0 version, on the other hand, has no keyboard and is equipped with the Hot-Line and autodialing function. It is a fixed GSM phone, which requires a SIM card to work. Smart features are available by default

  • Protection: IP66 – IK10
  • Temperature: -40°C +70°C
  • Humidity: up to 98%
  • MTBF: >180.000 h
  • MTTR: 3 min
  • Keypad aluminium Ø16mm
  • Bell 95dB at 1 meter
  • Handset cord INOX 200kg
  • LED «on line» Red
Smart Function
  • AFD Automatic Fault Detection
  • TelDia compatibility
  • LED «status» Blu
Accessories
  • Bell 110dB (230Vac)
Order codes
  • GSM700T with keypad
  • GSM700M0 without keypad

Options

Flashing Light

The LED flashing light on the top of the phone is available in different colors: WHITE, ORANGE, BLUE, RED, GREEN. In the analog versions it is powered by telephone line, while in the VoIP and GSM versions it requires auxiliary power supply. It can carry out the function of repeating incoming calls, be activated during the conversation or remain permanently on to indicate the position of the phone. It is also possible to install a 15 Joules Xenon version powered at 230Vac

Loud Bells 110dB

All the telephones in the ERCOTEL® range are equipped with an electronic ringtone of 95dB to 1 meter. However, it is possible to increase the sound signal up to 110dB, adding a special electronic card powered at 24Vdc or 230Vac. The basic ringtone is still active in the event of a power failure Auxiliary.

Enabling key

For some applications it is necessary to allow the use of the telephone only by authorized personnel. An enabling key is available for this.

Socket for headphones

Generally used in areas with very high ambient noise, the jack allows the connection of a noise-reducing headset with a microphone

Graphic symbols and instructions

The door allows you to support graphic symbols of all kinds. Furthermore, it is possible to use the internal surface of the door to support tables with telephone numbers and special instructions for operators

Version without door

ERCOTEL® also includes a version without door, which of course still guarantees IP66 and IK10 protection. There are indeed numerous applications where the door is not needed and sometimes causes a nuisance to the operators. With the versions called 710 it is possible to obtain all the ERCOTEL® performances, even in the absence of the door

Bi-standard telephone



ERCOTEL® offers the possibility of operating simultaneously on two networks in a totally redundant way. Versions are available that can operate on VoIP and GSM networks or on PSTN and GSM networks. This allows you to get a totally redundant phone able to guarantee operation even in case of crash of one of the two networks.

The audio interface is also redundant, with a handset and a separate speaker microphone group for hands-free conversation. This is made possible by the proven AFD (Automatic Fault Detection) technology
