NAVYPHONE®
Strong GRP body with and without door.
NAVYPHONE® is a family of weather-proof telephones expressly created for the corrosive marine environment, but consequently suitable for multiple applications in industrial and railway environments. The body of the phone it is made of GRP (Glass Reinforced Polyester), a very strong insulating material, used with generous thicknesses. The degree of protection is IP66, even with the door open. The door participates in keeping the handset clean, but it is also a support for pictograms and graphics, to clearly shows to the personnel the function to which the phone is dedicated. Several versions are available, with stainless steel cord or spiral, with or without door, with keyboard, without keyboard and on request with additional buttons. The telephone has an IK08 impact resistance when the door is open and IK10 when it is closed. Available in version with 95dB ringtone with open/closed door.
TEL605T
with keypad
TEL605T is equipped with a telephone keypad with 15 dual function buttons, with 8 memories for short numbers that can be recalled with the Fn key. It is available in analog, VoIP and GSM versions.
- Protection IP66 – IK08
- Temperature -40°C +70°C
- Humidity up to 98%
- MTBF >180.000 h
- MTTR 3 min
- Keypad 15 keys
- Ringtone 65 ÷ 95dB at 1 meter
- Handset cord INOX or spiral cord
- LED «on line» Red
- AFD Automatic Fault Detection
- Blue «status» LED
- TelDia compatibility
- 95dB ringtone with closed door
- Flash Xeno
- TEL605T-50S analog
- TEL605T-50S-Sm analog Smart
- TEL605T-50S-ip VoIP
- TEL700T-50S-ip-Sm VoIP (SIP) Smart
- TEL605T-50X analog
- TEL605T-50X-Sm analog Smart
- TEL605T-50X-ip VoIP
- TEL605T-50X-ip-Sm VoIP Smart
TEL605M0
Hot-Line / SOS
TEL605M0 is generally intended for the Emergency service, SOS, Hot-Line. Without the keypad, it dials one or more pre-stored telephone numbers when the handset is lifted (autodialing function). It is available in analog, VoIP and GSM versions.
- Protection IP66 – IK08
- Temperature -40°C +70°C
- Humidity up to 98%
- MTBF >180.000 h
- MTTR 3 min
- Ringtone 65 ÷ 95dB at 1 meter
- Handset cord INOX or spiral cord
- LED «on line» Red
- AFD Automatic Fault Detection
- Blue «status» LED
- TelDia compatibility
- 110dB (230Vac) Sonnerie: closed door
- Flash Xenon
- TEL605M0-50S analog
- TEL605M0-50S-sm analog Smart
- TEL605M0-50S-ip VoIP
- TEL605M0-50S-ip-Sm VoIP (SIP) Smart
- TEL605M0-50X analog
- TEL605M0-50X-Sm analog Smart
- TEL605M0-50X-ip VoIP
- TEL605M0-50X-ip-Sm VoIP Smart
TEL610T
with keypad
TEL610T is equipped with a telephone keypad with 15 dual function buttons, with 8 memories for memorized numbers that can be recalled with the Fn key. It is available in analog version, VoIP and GSM.
- Protection IP66 – IK08
- Temperature -40°C +70°C
- Humidity up to 98%
- MTBF >180.000 h
- MTTR 3 min
- Keypad 15 buttons
- Ringtone 95dB at 1 meter
- Handset cord INOX or spiral cord
- LED «on line» Red
- AFD Automatic Fault Detection
- Blue «status» LED
- TelDia compatibility
- Flash Xenon
- TEL610T-50S analog
- TEL610T-50S-sm analog Smart
- TEL610T-50S-ip VoIP
- TEL610T-50S-ip-Sm VoIP (SIP) Smart
- TEL610T-50X analog
- TEL610T-50X-Sm analog Smart
- TEL610T-50X-ip VoIP
- TEL610T-50X-ip-Sm VoIP Smart
TEL610M0
Hot-Line / SOS
TEL610M0 is generally used for the Emergency service, SOS, Hot-Line. Without keyboard it dials one or more pre-stored telephone numbers when lifting the handset (autodialing function). It is available in analog version, VoIP and GSM.
- Protection IP66 – IK08
- Temperature -40°C +70°C
- Humidity up to 98%
- MTBF >180.000 h
- MTTR 3 min
- Keypad 15 buttons
- Ringtone 95dB at 1 meter
- Handset cord INOX or spiral cord
- LED «on line» Red
- AFD Automatic Fault Detection
- Blue «status» LED
- TelDia compatibility
- Flash Xeno
- TEL610M0-50S analog
- TEL610M0-50S-sm analog Smart
- TEL610M0-50S-ip VoIP
- TEL610M0-50S-ip-Sm VoIP (SIP) Smart
- TEL610M0-50X analog
- TEL610M0-50X-Sm analog Smart
- TEL610M0-50X-ip VoIP
- TEL610M0-50X-ip-Sm VoIP Smart
