STEELPHONE®

Stainless steel INOX body, with aluminum handset.

STEELPHONE® is a waterproof and vandal-resistant telephone, suitable for wall or recessed installation, made of stainless-steel with IP66 protection degree and IK10 impact resistance. The keyboard is made with 12 metallic buttons and a status indication LED. The handset made of aluminum is equipped with a stainless-steel cord resistant to the traction > 200kg. The ringtone reaches 95dB at 1 meter. Suitable for use for public service (for example columns and information kiosks) but also in prison institutions as well as in the food industry. The SMART versions are equipped with numerous additional functions, as well as the automatic fault detection function (AFD Automatic Fault Detection)

TEL246TP
for wall with keypad

PDF icon ANALOG

TEL246TP is equipped with a telephone keypad with 15 dual-function buttons, with 8 memories for pre-memorized numbers recallable with the Fn key. It is available in analog and VoIP versions.

  • Body Stainless Steel
  • Handset Aluminium
  • Protection IP66 – IK10
  • Temperature -40°C +70°C
  • Humidity up to 98%
  • MTBF >180.000 h
  • MTTR 3 min
  • Metal buttons 15 buttons
  • Ringtone 95dB at 1 meter
  • Handset cord INOX 200kg
  • LED «on line» Red
Smart Options
  • AFD Automatic Fault Detection
  • Blue «status» LED
  • TelDia compatibility
Accessories
  • Call repeater relay
  • Up to 3 relays with DTMF password
Order Codes
  • TEL246TP analog
  • TEL246TPSm analog Smart
  • TEL246TP-ip VoIP
  • TEL246TP-ip-Sm VoIP Smart

TEL246M0P
for wall without keypad

PDF icon ANALOG

TEL246M0P has no keyboard and is designed to perform auto-dialing and Hot-Line service. It is available in analog and VoIP versions.

  • Body Stainless Steel
  • Handset Aluminium
  • Protection IP66 – IK10
  • Temperature -40°C +70°C
  • Humidity up to 98%
  • MTBF >180.000 h
  • MTTR 3 min
  • Ringtone 95dB at 1 meter
  • Handset cord INOX 200kg
  • LED «on line» Red
Smart Options
  • AFD Automatic Fault Detection
  • Blue «status» LED
  • TelDia compatibility
Accessories
  • Call repeater relay
  • Up to 3 relays with DTMF password
Order Codes
  • TEL246M0P analog
  • TEL246M0PSm analog Smart
  • TEL246M0P-ip VoIP
  • TEL246M0P-ip-Sm VoIP Smart

TEL246TF
recessed with keypad

PDF icon ANALOG

TEL246TF is equipped with a telephone keypad with 15 dual-function buttons, with 8 memories for pre-memorized numbers recallable with the Fn key. It is available in analog and VoIP versions

  • Body Stainless Steel
  • Handset Aluminium
  • Protection IP66 – IK10
  • Temperature -40°C +70°C
  • Humidity up to 98%
  • MTBF >180.000 h
  • MTTR 3 min
  • Metal buttons 15 buttons
  • Ringtone 95dB at 1 meter
  • Handset cord INOX 200kg
  • LED «on line» Red
Smart Options
  • AFD Automatic Fault Detection
  • Blue «status» LED
  • TelDia compatibility
Accessories
  • Call repeater relay
  • Up to 3 relays with DTMF password
Order codes
  • TEL246TF analog
  • TEL246TFSm analog Smart
  • TEL246TF-ip VoIP
  • TEL246TF-ip-Sm VoIP Smart

TEL246M0F
recessed no-keypad

PDF icon ANALOG

TEL246M0F has no keyboard and is designed to perform the auto-dialing and Hot-Line service. It is available in analog and VoIP versions.

  • Body Stainless Steel
  • Handset Aluminium
  • Protection IP66 – IK10
  • Temperature -40°C +70°C
  • Humidity up to 98%
  • MTBF >180.000 h
  • MTTR 3 min
  • Ringtone 95dB at 1 meter
  • Handset cord INOX 200kg
  • LED «on line» Red
Smart Options
  • AFD Automatic Fault Detection
  • Blue «status» LED
  • TelDia compatibility
Accessories
  • Call repeater relay
  • Up to 3 relays with DTMF password
Order Codes
  • TEL246M0F analog
  • TEL246M0FSm analog Smart
  • TEL246M0F-ip VoIP
  • TEL246M0F-ip-Sm VoIP Smart
