STEELVOX®

INOX body for recessed mounting, IP66 and IK10

STEELVOX® is a recessed mounting industrial hands-free telephone, consisting of a stainless-steel body of exceptional strength (2mm thickness), with IP66 protection degree. The buttons are made of aluminum and there is a status indication LED. All external parts of the phone are impact resistant with IK10 grade. It is supplied in Analog, VoIP or GSM version. There are numerous SMART functions performed by this phone, including automatic answering after a predefined number of rings, repetition of the call by means of optical and acoustic and external devices, activation of relays upon entering a DTMF password, automatic typing of pre-stored numbers (autodialing). It is compatible with the Smart options package, which includes Automatic Fault Detection (AFD) and remote interrogation.

TEL249T
with keypad

PDF icon ANALOG
PDF icon VoIP

TEL249T is equipped with a telephone keypad with 15 dual-function buttons, with 8 memories for stored numbers recallable with the Fn key. It is available in Analog, VoIP and GSM versions. It is generally used for service communications and to authorize entry into departments and buildings, thanks to the remote-controlled relays available as an option.

  • Body Stainless Steel
  • Protection IP66 – IK10
  • Temperature -40°C +70°C
  • Humidity up to 98%
  • MTBF >180.000 h
  • MTTR 3 min
  • Metal buttons 15 buttons Ø 13mm
  • Ringtone 85dB at 1 meter
  • LED «on line» Red
Smart Options
  • AFD Automatic Fault Detection
  • Blue «status» LED
  • TelDia compatibility
Accessories
  • Remote control relay (up to 3 relays)
  • Booster amplifier (95dB)
  • Fault Alarm Module FAR-01
  • Headphone jack
Order Codes
  • TEL249T analog
  • TEL249TSm analog Smart
  • TEL249T-VoIP VoIP (SIP)
  • TEL249TVoIP-Sm VoIP (SIP) Smart
  • GSM249T GSM
  • GSM249TSm GSM Smart

TEL249M1
1 button

PDF icon ANALOG
PDF icon VOIP

TEL249M1 is equipped with a single metal button for calling pre-stored numbers. It is available in Analog, VoIP and GSM versions. It is generally used for emergency and service communications and to authorize entry into departments and buildings, thanks to the remote-controlled relays available as an option.

  • Body Stainless Steel
  • Protection IP66 – IK10
  • Temperature -40°C +70°C
  • Humidity up to 98%
  • MTBF >180.000 h
  • MTTR 3 min
  • Pulsante Aluminium Ø 20mm
  • Ringtone 85dB at 1 meter
  • LED «on line» Red
Smart Options

AFD Automatic Fault Detection
Blue «status» LED
TelDia compatibility

Accessories
  • Remote control relay (up to 3 relays)
  • Booster amplifier (95dB)
  • Fault Alarm Module FAR-01
  • Headphone jack
Order Codes
  • TEL249M1 analog
  • TEL249M1Sm analog Smart
  • TEL249M1-VoIP VoIP (SIP)
  • TEL249M1VoIP-Sm VoIP (SIP) Smart
  • GSM249M1 GSM
  • GSM249M1Sm GSM Smart

TEL249M4
4 buttons

PDF icon ANALOG
PDF icon VOIP

TEL249M4 is equipped with 4 metal buttons for calling pre-stored numbers. It is available in Analog, VoIP and GSM versions. It is generally used for emergency and service communications and to authorize entry into departments and buildings, thanks to the remote-controlled relays available as an option.

  • Body Stainless Steel
  • Protection IP66 – IK10
  • Temperature -40°C +70°C
  • Humidity up to 98%
  • MTBF >180.000 h
  • MTTR 3 min
  • Keypad Aluminium Ø 13mm
  • Ringtone 85dB at 1 meter
  • LED «on line» Red
Smart Options
  • AFD Automatic Fault Detection
  • Blue «status» LED
  • TelDia compatibility
Accessories
  • Remote control relay (up to 3 relays)
  • Booster amplifier (95dB)
  • Fault Alarm Module FAR-01
  • Headphone jack
Order codes
  • TEL249M4 analog
  • TEL249M4Sm analog Smart
  • TEL249M4-VoIP VoIP (SIP)
  • TEL249M4VoIP-Sm VoIP (SIP) Smart
  • GSM249M4 GSM
  • GSM249M4Sm GSM Smart

TEL249M8
8 buttons

PDF icon ANALOG
PDF icon VOIP

TEL249M8 is equipped with 8 metal buttons for calling pre-stored numbers. It is available in Analog, VoIP and GSM versions. It is generally used for emergency and service communications and to authorize entry into departments and buildings, thanks to the remote-controlled relays available as an option.

  • Body Stainless Steel
  • Protection IP66 – IK10
  • Temperature -40°C +70°C
  • Humidity up to 98%
  • MTBF >180.000 h
  • MTTR 3 min
  • Keypad Aluminium Ø 13mm
  • Ringtone 85dB at 1 meter
  • LED «on line» Red
Smart Options
  • AFD Automatic Fault Detection
  • Blue «status» LED
  • TelDia compatibility
Accessories
  • Remote control relay (up to 3 relays)
  • Booster amplifier (95dB)
  • Fault Alarm Module FAR-01
  • Headphone jack
Order Codes
  • TEL249M8 analog
  • TEL249M8Sm analog Smart
  • TEL249M8-VoIP VoIP (SIP)
  • TEL249M8VoIP-Sm VoIP (SIP) Smart
  • GSM249M8 GSM
  • GSM249M8Sm GSM Smart
