HARDYPHONE®

Compact aluminum body and handset.

HARDYPHONE® is an industrial telephone of the highest quality and robustness, entirely made of die-cast aluminum, with IP66 protection degree. The keyboard is made with 12 aluminum Ø16mm buttons, 3 buttons Ø13mm for optional functions and a status indication LED. All external parts of the telephone are impact resistant with IK10 grade. The stainless-steel cord of the handset withstands a traction> 200kg. The ringtone reaches 95dB at 1 meter. The handset is made of aluminum, but a version with a polycarbonate handset is available. The numerous optional functions include the Full-Duplex handsfree conversation. The optional Smart package includes many high-level features, including Automatic Fault Detection (AFD) and TelDia® Remote Control.

TEL457T
ALU Handset

PDF icon ANALOG
PDF icon VoIP (SIP)

TEL457T is equipped with a telephone keypad with 15 dual-function buttons, with 8 memories for pre-memorized numbers recallable with the Fn key. It is available in analog and VoIP versions.
Handset Aluminium.

  • Protection IP66 – IK10
  • Temperature -40°C +70°C
  • Humidity up to 98%
  • MTBF >180.000 h
  • MTTR 3 min
  • Metal buttons 15 buttons
  • Ringtone 95dB at 1 meter
  • Handset cord INOX 200kg
  • LED «on line» Red
Smart Options
  • Blue «status» LED
  • AFD Automatic Fault Detection
  • TelDia compatibility
Accessories
  • Headphone Jack
Order Codes
  • TEL457T analog
  • TEL457TSm analog Smart
  • TEL457TVSm analog Smart + VV
  • TEL457T-VoIP VoIP (SIP)
  • TEL457T-VoIPSm VoIP (SIP) Smart

TEL456T
Plastic Handset

PDF icon ANALOG

TEL456T is equipped with a telephone keypad with 15 dual-function buttons, with 8 memories for pre-memorized numbers recallable with the Fn key. It is available in analog and VoIP versions.

  • Handset Polycarbonate
  • Protection IP66 – IK10
  • Temperature -40°C +70°C
  • Humidity up to 98%
  • MTBF >180.000 h
  • MTTR 3 min
  • Metal buttons 15 buttons
  • Ringtone 95dB at 1 meter
  • Handset cord INOX 200kg
  • LED «on line» Red
Smart Options
  • Blue «status» LED
  • AFD Automatic Fault Detection
  • TelDia compatibility
Accessories
  • Headphone Jack
Order Codes
  • TEL456T analog
  • TEL456TSm analog Smart
  • TEL456TVSm analog Smart + VV
  • TEL456T-VoIP VoIP (SIP)
  • TEL456T-VoIPSm VoIP (SIP) Smart

TEL457M0
Hot-Line / SOS

PDF icon ANALOG
PDF icon VoIP (SIP)

TEL457M0 is generally used for the Emergency service, SOS, Hot-Line. Without a keyboard, it can dial one or more pre-stored telephone numbers when lifting the handset (auto dialing function). It is available in analog and VoIP versions.

  • Handset Aluminium
  • Protection IP66 – IK08
  • Temperature -40°C +70°C
  • Humidity up to 98%
  • MTBF >180.000 h
  • MTTR 3 min
  • Keypad 15 buttons
  • Ringtone 95dB at 1 meter
  • Handset cord INOX 200kg
  • LED «on line» Red
  • LED «status» Blu
Smart Options
  • AFD Automatic Fault Detection
  • TelDia compatibility
Accessories
  • Flash Xeno
Order codes
  • TEL457TM0S analog Smart
  • TEL457M0-VoIPSm VoIP (SIP) Smart

OPTIONS

Jack socket for headphones

The optional jack allows the connection of a noise-reducing headset with microphone, generally used in areas with very high ambient noise

Relay door opener

On request, the phone can support an activated remote-control relay using DTMF password. One of the keys is dedicated to performing the door opener function.

Graphic Symbols

On the models without keyboard, customized graphics can be released on demand.

Special versions

It is possible to make special versions with a number of buttons different from the standard. In some cases, it is possible to assign different functions to the buttons, by means of custom firmware
