CONTROLPHONE™
The CONTROLPHONE™ series derives from over 30 years of experience in the design and production of special communication terminals, conceived to be installed in the most challenging areas. These robust industrial professional phones are designed for use in control rooms of industrial plants. The TEL161TD-Sip-Plus is a professional VoIP (SIP) phone for desktop mounting, suitable for installation in Emergency and Control Rooms, featuring an aluminum body and a durable metal keypad, with a handset for private conversations, and an automatic fault detection (AFD) function that includes audio testing of the microphone and handset, compatible with TelDia™. The body of the TEL161TD-Sip-Plus is made of aluminum, with individual highly robust metal buttons. The keypad is protected by IP66 while the entire phone is protected by IP42. Equipped with the native VoIP electronic board XCS-182 version 2024-1, HD Voice, ready for DESQO™.
TEL161TD-Plus
The phone is equipped with a complete telephone keypad with 16 individual aluminum buttons, Ø 16 mm.
• 12 buttons (*, #, 0, 1…9)
• Volume adjustment V+, V-
• Hook button
• PTT button (optional)
At the bottom of the 4-inch touch screen, there are 4 additional metal buttons Ø 13 mm named F1, F2, F3, and F4. These buttons can be assigned user-selected functions.
